Collection: QX Platform 73 L

Functions:

• 0+4
• 0+6
• 0+7
• 0+8
• 0+9
• 0+10

* Fryart (airfry) function is available with turbo fan and turbo resistance functions together with a special tray given.

Colours:

• Dove grey: compatible with ash grey glass
• Platinium grey: compatible with matte black
• Pearly midnight

Control Panel:

• Glass (Black / White)
• Metal (Inox / Painted enamel)

Display:

• Entry level: with 4 buttons located below the timer
• 2 button version with electronic thermostat works with +/- 1 degrees oscillation.
• TFT circular control (Ongoning Project): Slim and large similar to AEG models, having slider control. There are 2 slider alternatives which are flat and circular; both with a light following the finger motion.

***Timer turns off the the heating after the cooking time is over.

Door glass:

• 2 glasses (Models without cooling fan can be produced without Lowe)
• 3 glasses (Lowe is optional)
• 4 glasses are available for only pyrolitic models.

Lowe glass is standard for models having cooling fan, optional for others.

Inner glasses are default from Schott.

KEY FEATURES/NOTES:

• Cooling fan:
  • It is a MUST for decorated control panels, which are inox, painted or having digital timer, as well as all QY platform models.
  • It is OPTIONAL for metal painted or glass control panels; in compliance with CE standards.
  • Operates silently after cooking without causing any inconvenience.

• Electronic limit thermostat
• Minimum order qty: 54 (TO BE CONFIRMED LATER)
• There is a possibility of different platforms divided according to the display with digital vs non-digital products in the future.
• Soft-close option
• Door switch option: Lamp turns on automatically.
• Dimmer option: When lamp turns on, the light brightens slowly.
• Under door decoration can be painted or stainless.
• Embossed cavity or sidewire rack options. Tray dimensions are the same for both versions.

    Lamp is located on the right back upper side of the oven ceiling for QX platform models; and on upper side of the ceiling for QY platform models.Square lamp on left oven wall option is available for models having side-wire rack.

 Hardly no vapouration or sublimation on the inner door glass.

• Registered features:
  • FRYART…. For airfry feature
  • STEAMART….For steam added cooking feature
  • DIMMINGART….slowly turning off lamp
• Diffent hinge system from Atasan.
• Commutator: Ege
• Heater: Irka/Ege
• White isolation: standard
• Door system: Detachable
• Accessories:
• Standard tray, deep tray (optional), fryart tray (available default with fryart feature), grid, meat probe, rotisserie, telescopic rail.
• Trays are heavier in weight than other trays in the market.
• Heating can reach 200C within 6,5-7 minutes. (2000W turbo)
•
  New designed cavity has a special curve that provides as optimal air circulation
• QR codes are available on the door sides in order to access the assembly details of the door glasses.
